Prefab Educational Building School Facility Folding Container House Fast Easy Deployment
The folding container house, tailored for educational use, boasts durability, swift installation, safety, eco-friendliness, adaptability, and customizable interiors. Crafted from premium materials, it endures harsh conditions and ensures a lengthy lifespan. Its foldable design facilitates seamless setup and dismantling, making it perfect for temporary or scalable school expansion. Safety is paramount, with fire-resistant materials and a robust framework. Environmentally conscious, it incorporates recyclable materials and supports renewable energy sources. Its portability ensures it can be relocated to cater to evolving school requirements. The customizable interiors create a functional and cozy learning and living environment for studentstiny
| Standard Foldable Container House Datasheet | ||||
| Product specifications | External size(L*W*H) | 5800mm*2480mm*2520mm | ||
| Inner size(L*W*H) | 5588mm*2268mm*2160mm | |||
| Folding height | 570mm | Unit weight | 1300kg | |
| Design parameter | Thermal insulation | λ=0.048W/m·K | wind resistance | 0.60kN/㎡ |
| Sound insulation | ≥30dB | Fireproof performance | Class A | |
| Waterproof performance | 360 degrees bite connection, organized drainage,no leakage under precipitation 16mm/min | Seismic performance | 8 degree | |
| Floor live load | 2.0kN/㎡ | Roof live load | 1.0kN/㎡ | |
| Item | part | Spec(mm) | Unit | Qty |
| Frame | Corner piece(l*w*h*t) | Top 220*140*190*3.75,material Q235 | pc | 4 |
| Bottom 220*140*160*3.75,material Q235 | pc | 4 | ||
| Column(l*w*h*t) | 220*140*2500*2.2,material Q235 | pc | 4 | |
| Bottom frame | 160*2.45 main beam,material Q235 | pc | 4 | |
| 120*1.2 second beam,material Q235 | pc | 9 | ||
| Top frame | 160*2.2 main beam,material Q235 | pc | 4 | |
| C80*40*1.5 second beam,materialQ235 | pc | 6 | ||
| 20*20*1.2 purlin,material Q235 | pc | 4 | ||
| Surface treatment | electrostatic spraying plastic powder baking paint | set | 1 | |
| container body | Roof panel | color steel panel,360°bite connection t=0.36mm | set | 1 |
| Ceiling decoration | 170 type color steel integrated board t=0.3mm | pc | 34 | |
| Heat-insulating layer | Glass wool roll mat, thickness 50mm, capacity 28kg/m³, combustion performance of class A non-combustible. | set | 1 | |
| Floor structure board | 18mm glass-magnesium board | pc | 5 | |
| Floor decoration | Manual pvc flooring leather, thickness 1.6mm | set | 1 | |
| Left and right walls (surrounded by galvanized groove edging) | 950 type 50 series rock wool double white color steel composite panel with double-sided film, steel plate t=0.3mm, rock wool 60kg/m³ | pc | 2 | |
| Front walls (surrounded by galvanized groove edging) | 950 type 50 series rock wool double white color steel composite panel with double-sided film, steel plate t=0.3mm, rock wool 60kg/m³ | pc | 1 | |
| Rear walls (surrounded by galvanized groove edging) | 950 type 50 series rock wool double white color steel composite panel with double-sided film, steel plate t=0.3mm, rock wool 60kg/m³ | pc | 1 | |
| Door&Window | Door | Steel set door, size W925mm×H1970mm, steel plate t=0.4mm | pc | 1 |
| Window | Upvc series plastic steel sliding window, size: W925mm×h1100mm; single-glazed, with anti-theft mesh, with screens | pc | 2 | |
| Folding accessories | Lifting parts, folding parts | set | 1 | |
Electrical&Wire (indoor) |
Light | LED600*300 rectangular light | set | 2 |
| Socket | 10A five-hole socket | pc | 4 | |
| Socket | 16A air conditioner socket | pc | 1 | |
| Switch | single-button switch | pc | 1 | |
| Distribution box | which is equipped with a 2P32A leakage protection and two single 16A circuit breakers. | set | 1 | |
| CEE Industrial plug | 220V,50Hz | pc | 1 | |
| Wire | Distribution Wire:3*6 square,AC socket:3*4 square,five-hole socket:3*2.5 square,Light:3*1.5 square | set | 1 | |
